Main functions: PC intelligent system → separating agent → servo feeding gauge → servo pre-milling 1 → infrared baking lamp → 20KG PUR glue machine → no-clean gluing device → 6-channel servo tape feeding → five-wheel pressing → heavy-duty rough edge trimming → magnetic levitation end trimming → heavy-duty servo double-disc double-R edge trimming → heavy-duty servo double-disc double-R edge scraping → magnetic levitation tail trimming →flat scraping → four-head tracking (servo tool adjustment) → cleaning agent → single-group polishing
| 型号 | Model | NC826-2 |
| 电动升降 | Electrical Lift | ● |
| 总功率 | Motor Power | 39.18kw |
| 外形尺寸 | Overall size(L*W*H) | 9800*970*1970mm |
| 进给速度 | Feed Speed | 16-23-26-29-32m/min |
| 板料宽度 | Panel Width | ≥ 65mm |
| 板料厚度 | Panel Thickness | 8~60mm |
| 封边带宽度 | Edge Tape Width | 15~65mm |
| 封边带厚度 | Edge Tape Thickness | 0.4-3mm |
| 整机重量 | The whole weight | 6500KG |
